Specification:
Antenna Size |
10 ft. |
Antenna Type |
Folding |
Feed |
Prime Focus |
F/D Ratio |
0.4 |
Focal Length |
48 Inches |
Penal |
Aluminum Mesh Painted |
Mount |
AZ / EL |
Stability |
AZ 360 Degree EL to 90 Degrees |
Total Ribs |
24 |
Dual Ribs |
8 |
Reflector Material |
Fully Aluminum |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4 GHz. – 13 GHz. |
Pointing |
Manual |
Gain |
40.25 dB at 4Ghz |
Approximate Weight. |
45 Kg. |
Specification:
Antenna Size |
9 ft. |
Antenna Type |
Parabolic |
Feed |
Prime Focus |
f/d Ratio |
0.42 |
Focal Length |
45.00 Inch |
Mesh |
Aluminum Punched sheet |
Mount |
AZ / EL |
Stability |
AZ 360 Degree EL to 90 Degrees |
Ribs |
24 |
Segments |
Aluminum Alloy |
Reflector Material |
Aluminum |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4 GHz. – 13 GHz. |
Pointing |
Manual |
Gain |
39.34 dB at 4GHz |
Approximate Weight. |
30 Kgs. |
7 ft. C/KU band Dish Antenna Fully Aluminum
Specification:
Antenna Size |
7 ft. 210Cm. |
Modal |
C/Ku/18S |
Antenna Type |
Parabolic |
Feed |
Prime Focus |
f/d Ratio |
0.42 |
Focal Length |
33.12. Inch |
Mesh |
Aluminum Punched sheet |
Total Segments |
12 |
Stability |
AZ 360 Degree EL to 90 Degrees |
Mount |
Polar |
Reflector Material |
Aluminum Alloy |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.6 GHz. – 13 GHz. |
Pointing |
Manual |
Gain |
34 dB |
Approximate Weight. |
20 Kg. |
12 feet C-Band Dish antenna 24 and 36 Segments Fully Aluminum
Specification:
Antenna Size |
12 ft. |
Antenna Type |
Folding |
Feed |
Prime Focus |
F/D Ratio |
0.4 |
Focal Length |
57.60 Inch |
Penal |
Aluminum Mesh Painted |
Mount |
AZ / EL |
Stability |
AZ 360 Degree EL to 90 Degrees |
Double Ribs |
8/12 |
Total Ribs |
24/36 |
Reflector Material |
Aluminum Reinforced with steel |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4 GHz. – 5GHz. |
Pointing |
Manual |
Gain |
41.83 dB at 4GHz |
Approximate Weight. |
75 Kg. |
6 ft. C/Ku band Dish Antenna Fully Aluminum
Specification:
Antenna Size |
6ft. 180Cm. |
Modal |
C/Ku/12S |
Antenna Type |
Parabolic |
Feed |
Prime Focus |
f/d Ratio |
0.40 |
Focal Length |
29.72. Inch |
Mesh |
Aluminum Punched sheet |
Total Segments |
12 |
Stability |
AZ 360 Degree EL to 90 Degrees |
Mount |
Polar |
Reflector Material |
Aluminum Alloy |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4GHz. – 12GHz. |
Pointing |
Manual |
Gain |
35.81dB |
Approximate Weight. |
14 Kgs. |
8ft. C-band Dish antenna Fully Aluminum
Specification:
Antenna Size |
8 ft. |
Antenna Type |
Parabolic |
Feed |
Prime Focus |
f/d Ratio |
0.42 |
Focal Length |
40.00 Inch |
Penal |
Aluminum Punched sheet |
Mount |
AZ / EL |
Stability |
AZ 360 Degree EL to 90 Degrees |
Total Ribs |
18/24 |
Reflector Material |
Aluminum Alloy |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4GHz. – 13GHz. |
Pointing |
Manual |
Gain |
38.31 dB at 4GHz |
Approximate Weight. |
28 Kg. |
16ft C band Dish antenna Fully Aluminum
Specification:
Antenna Size |
16 ft. |
Antenna Type |
Parabolic |
Feed |
Prime Focus |
f/d Ratio |
0.40 |
Focal Length |
76.80 Inch |
Penal |
Aluminum Punched Sheet |
Mount |
AZ / EL |
Stability |
AZ 360 Degree EL to 90 Degrees |
Double Ribs |
16 |
Total Ribs |
48 |
Reflector Material |
Aluminum Alloy |
Wind load operational |
75 Kmph |
Survival Wind Speed |
120 Kmph |
Polarization |
Linear & Circular |
Pointing Accuracy |
Better Than + / – 0.2 Deg. |
Operating Frequency |
3.4 GHz. – 5 GHz. |
Pointing |
Manual |
Gain |
44.33 dB at 4 GHz |
Approximate Weight. |
235 Kg. |
