15 ft. Ku band Dish antenna


15ft. Ku-band dish antenna

Specification:

Antenna Size 15 ft.
Antenna Type Folding
Feed Prime Focus
f/d Ratio 0.67
Focal Length 120.89 Inch
Penal Aluminum Mesh Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Double Ribs 16
Total Ribs 48
Reflector Material Aluminum Reinforced with steel
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 10 GHz. – 13 GHz.
Pointing Manual
Gain 47.4 db at 11000 Ghz
Approximate Weight. 240 Kgs.

10ft. C-Band Dish antenna D.

10ft. C-band Dish antenna Fully Aluminum Dual Ribs



Specification:

Antenna Size 10 ft.
Antenna Type Folding
Feed Prime Focus
F/D Ratio 0.4
Focal Length 48 Inch
Penal Aluminum Mesh Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Total Ribs 24
Dual Ribs 8
Reflector Material Fully Aluminum
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.4 GHz. – 13 GHz.
Pointing Manual
Gain 40.25 db at 4Ghz
Approximate Weight. 60 Kgs.

7 ft. Ku-Band Dish Antenna

7 ft. Ku-Band Dish Antenna

Specification

Antenna size 7ft. 210Cm.
Focal Length 56.53 Inch
Band Ku band
Mount AZ / EL
Stability AZ 360 Deg. EL 0 to 90 Deg.
Total Ribs  18
Reflector Material Aluminum Sheet/Mesh
Wind load operational 75 Kmph
Survival Wind Speed 100Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency  10 to 13 GHz.
Pointing Manual
Gain 34.1 db
Approximate Weight. 35 Kgs.

10ft. C-Band Dish Antenna S.

10ft. C-band Dish antenna Fully Aluminum Single Ribs



Specification:

Antenna Size 10 ft.
Antenna Type Folding
Feed Prime Focus
F/D Ratio 0.4
Focal Length 48 Inch
Penal Aluminum Mesh Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Total Ribs 24
Reflector Material Fully Aluminum
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.4 GHz. – 13 GHz.
Pointing Manual
Gain 40.25 db at 4Ghz
Approximate Weight. 50 Kgs.

9 ft. C Band Dish Antenna

9ft. C-band Dish antenna Fully Aluminum



Specification:

Antenna Size 9 ft.
Antenna Type Folding
Feed Prime Focus
F/D Ratio 0.4
Focal Length 43.26 Inch
Penal Aluminum Mesh Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Ribs 18
Total Ribs 18
Reflector Material Fully Aluminum
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.4 GHz. – 13 GHz.
Pointing Manual
Gain 39.34 db at 4Ghz
Approximate Weight. 38 Kgs.

7 ft. C-Band Dish Antenna

 7 ft. C/Ku band Dish Antenna Fully Aluminum



Specification:

Antenna Size 7 ft. 210Cm.
Modal C/Ku/18S
Antenna Type Folding
Feed Prime Focus
f/d Ratio 0.40
Focal Length 33.66. Inch
Mesh Aluminum Punch Sheet
Total Segments 18
Stability AZ 360 Degree EL to 90 Degrees
Mount Polar
Reflector Material Aluminum
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.6 GHz. – 13 GHz.
Pointing Manual
Gain 34 db
Approximate Weight. 26 Kgs.

6ft. Ku-band Dish antenna

6ft. Ku-band Dish antenna

Specification

Antenna size 6ft 180Cm.
Focal Length 47.42Inch
Band Ku band
Mount AZ / EL
Stability AZ 360 Deg. EL 0 to 90 Deg.
Total Ribs  18
Reflector Material Aluminum Sheet/Mesh
Wind load operational 75 Kmph
Survival Wind Speed 100Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency  10 to 13 GHz.
Pointing Manual
Gain 34.1 db
Approximate Weight. 30 Kgs.

14 ft. Ku band Dish antenna



Specification:

Antenna Size 14 ft.
Antenna Type Folding
Feed Prime Focus
f/d Ratio 0.67
Focal Length 111.78 Inch
Penal Aluminum Sheet Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Double Ribs 18
Total Ribs 36
Reflector Material Aluminum Reinforced with steel
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 10 GHz. – 13 GHz.
Pointing Manual
Gain 47.4 db at 11000 Ghz
Approximate Weight. 200 Kgs.

12 ft. C-Band Dish Antenna

12 feet C-Band Dish antenna 24 and 36 Segments Fully Aluminum



Specification:

Antenna Size 12 ft.
Antenna Type Folding
Feed Prime Focus
F/D Ratio 0.4
Focal Length 57.60 Inch
Penal Aluminum Mesh Painted
Mount AZ / EL
Stability AZ 360 Degree EL to 90 Degrees
Double Ribs 8/12
Total Ribs 24/36
Reflector Material Aluminum Reinforced with steel
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.4 GHz. – 5GHz.
Pointing Manual
Gain 41.83 db at 4Ghz
Approximate Weight. 90 Kgs.

6 ft. C-Band Dish Antenna

 6 ft. C/Ku band Dish Antenna Fully Aluminum



Specification:

Antenna Size 6ft. 180Cm.
Modal C/Ku/12S
Antenna Type Folding
Feed Prime Focus
f/d Ratio 0.40
Focal Length 29.45. Inch
Mesh Aluminum Punch Sheet
Total Segments 12
Stability AZ 360 Degree EL to 90 Degrees
Mount Polar
Reflector Material Aluminum
Wind load operational 75 Kmph
Survival Wind Speed 120 Kmph
Polarization Liner & Circular
Pointing Accuracy Better Than + / – 0.2 Deg.
Operating Frequency 3.4GHz. – 12GHz.
Pointing Manual
Gain 35.81db
Approximate Weight. 20 Kgs.
